It is commonly used in the industry for acceptance testing prior to energizing the cable and for maintenance testing programs. Curve a shows test values as measured. A if the insulation resistance of a new cleaned or repaired motor that has been stored for some time is less then 10 mω the reason might be that the windings are humid and.
